MAGELLAN
EXPANDO
Switching
Ross NextGen Carbonite
3 Mixed Effects
3 M/E Control Panel
Clean Feeds
Fully Routable
720p, 1080i, 1080p, 4k
Graphics
Ross Xpression 11.0
Custom Bug Boxes
Audio
Calrec Brio Audio Console
24 analog in / 16 analog out
Dante and Madi Cards, AD5781 field I/O 24x8 over Hydra Network
16 Channels Unity Intercom
2 Genelec Studio Monitors
2 Glensound Divine Dante Speakers
20 Cue speaker channels including p1, p2
8 Sennheiser MKH-416 shotgun mic
3 Studiotech Model 230 announce boxes
6 Sennheiser HMD26 announce headsets
Cameras
Wired for 12 fiber cameras
(4) 7" Studio viewfinder
(2) ENG 2" viewfinder _ _
4K POV cameras
-
Vinten Vector 70 heads
(4) Moog Quickset Legs
(3) Sachtler Video 20 tripods
Tape/Replay
EVS XT3 8 Channel & 6 In-2 Out
EVS XT3 8 Channel & 6 In-2 Out
EVS Xfile
DVCPro Deck
(1) Hyperdeck Shuttle
Kipro Drive*
Other
RTS ODIN digital matrix intercom
(8) KP panels
(4) RTS TIF-2000 Telco interface
(1) Telos HX2 Telco hybrid
(8) Wet PL and 8 wet IFB available
(8) RTS BP-325 beltpacks
(8) RTS 4030 IFB beltpacks
(1) RTS Biscuit box
(8) Studiotech Model 370A Dante beltpack
(4) Studiotech Model 380 on-air IFB beltpack
Terminal
(1) SAM Vega 400 72x108 router with MADI and embed/de-embed
-
Lawo V_pro8 8-channel processor
-
AJA FS4 frame sync Field monitors / Lighting
(4) 21" HD field monitor
(4) 19" Composite field monitor
-
Lighting kits (2 HMI and 2 LED panel)
Cable
150' AC feeder
SMTPE Fiber 6x 500' 6x 250' 6x 100' 6x 50'
DT12 6x 300' 4x 100'
5 wire BNC 4x 150'
-
1000' TAC12 fiber reel
Vehicle
Frontline, Peterbilt chassis
Overall dimensions 36'6"L x 100"W x 13'4"H
Gross weight 42000Ibs
Footprint 40'L x 17'W
Power
125A 3 phase 208
Lens
86x Canon Full Controls
20x Fuji for Handhelds
20x Fuji Wide Angle
(2) 55x Canon Lenses (2 Semi-Servo)
HD36
This new 1080p truck is designed for both full production and REMI.
A perfect footprint loaded with everything you need for your next event.
